UMS750 Mobile Shredder for Metal and Wood Recycling

Name: UMS750 Mobile Shredder for Metal and Wood Recycling | UPSEN
Brand: UPSEN
SKU: UMS750
Availability: InStock

Product Description

The UMS750 is a tracked mobile shredder that uses low-speed, high-torque twin-shaft cutting to reduce bulky, tough and metal-bearing waste into recyclable fractions.

It processes C&D waste, wood and biomass, municipal solid waste and, depending on model, scrap metal and end-of-life vehicles - rated up to 7 m³. A CUMMINS 8.9L-C360/264 kW engine provides the drive power. Operating weight is about 28,000 kg.

Output size is set by the screen configuration, and an optional over-belt magnet recovers ferrous metal from the output - the first step of any metal recycling line. Remote-controlled operation, tracked mobility and a 12-month warranty are standard on every UPSEN machine, with EU conformity documentation and OEM spare parts support for customers in 80+ countries.

Twin-shaft cutting handles wood, tyres, MSW, C&D and scrap metal
Optional over-belt magnet recovers ferrous metal
Screen configuration controls final output size
Electric-drive option available for indoor sites

Key Specifications

Engine

CUMMINS 8.9L-C360/264 kW

Total Weight

28,000 kg

Working Size

12850×650×850 mm(505.9×25.6×33.5 in)

Feed Inlet5100×300 mm (Hydraulic lifting)(200.8×11.8 in)

Hopper Capacity7 m³

Knife Disc Diameter730 mm(28.7 in)

Spindle Length2000 mm(78.7 in)

Spindle Speed0-42 r/min

Reducer Torque240,000 N/M

Cutter MaterialHARDOX 500 (NM500)

Hydraulic SystemLinde pump/motor, SUN valve

Main ConveyorB1200×0500 mm(B47.2×19.7 in)

Discharge Height3800 mm(149.6 in)

Iron Remover (opt.)B800×200

Track TypeSteel Track

Capacity (C&D)80-150 t/h

Capacity (Wood)40-60 t/h

Capacity (Scrap Metal)15-25 t/h

Transport Size9500×650×200 mm(374×25.6×7.9 in)

Detail Images

UMS750 at a glance

The UPSEN UMS750 is a tracked mobile shredder built for continuous duty in quarrying, concrete recycling and demolition work. Its rated output is - fed from a 7 m³/hopper and taking material up to 5100×300 mm (Hydraulic lifting) at the inlet.

The unit travels as one load on a low-bed trailer -9500×650×200 mm and 28,000 kg -and is driven by CUMMINS 8.9L-C360/264 kW, so no site power supply is needed. Steel tracks let the operator reposition the plant as the working face advances.

When specifying a tracked mobile shredder, always match the throughput of the crusher with the downstream screening and stockpiling equipment, and check the maximum feed size against the material you actually run. An oversized inlet wastes fuel; an undersized one causes bridging and blocked jaws.

Typical applications

Construction and demolition waste (C&D)
Municipal solid waste and bulky waste
Wood waste, pallets and green waste
Scrap metal and light steel

How the UMS750 compares

Model	Capacity	Max. feed size	Total weight
UMS750 (this model)	-/td>	5100×300 mm (Hydraulic lifting)	28,000 kg
UFS750	20-150 t/h	750 mm	12 tons
UMS250	-/td>	1200×500 mm	18,000 kg
UMS950	-/td>	2000×500 mm	49,000 kg

Recommended line-up for the UMS750

Based on rated capacity, the following UPSEN units are usually specified together with the UMS750:

UYK221 -mobile scalping screener · 30-80 t/h
UTD35 -tracked mobile stacker conveyor · 30-100 t/h

Frequently asked questions

What is the capacity of the UMS750?

Rated capacity is - Actual output depends on the material, the feed size and the discharge setting.

What is the maximum feed size?

The UMS750 accepts material up to 5100×300 mm (Hydraulic lifting).

How big and how heavy is the UMS750?

28,000 kg, transport size 9500×650×200 mm. It can be moved on a standard low-bed trailer without dismantling.

What drives the machine?

CUMMINS 8.9L-C360/264 kW.

Does the UMS750 come with EU conformity documentation, and how is it delivered?

Yes -UPSEN machines are supplied with EU conformity documentation and leave the factory ready for work. Delivery is by sea (container or flat rack) to major ports.

What are the payment, lead time and warranty terms?

Payment is 30% T/T deposit with the balance paid before shipment; an irrevocable L/C at sight is also accepted. Quotations are FOB Qingdao and valid for 30 days. Lead time is 15 days for standard models and 30 days for customised configurations, counted from receipt of deposit. The complete machine carries a 12-month warranty from commissioning, and wear parts such as jaw plates carry 6 months with a typical service life of 800-1,200 hours depending on the feed material. Full terms are on our trade terms and service.

Is the MS750 named in the EU conformity documents?

Yes. The MS750 is named in the ECM Mark certificate 0P250820.HFIQW55, the ICR Polska Verification of Conformity ICR Polska/VC/H211205, the ICR Polska noise verification ICR/VC/UA260915, the UDEM Attestation of Conformity M.2025.206.C128082 and the EN ISO 3744:2010 noise test report LTR20260909001. You can download the original documents from our certifications and compliance page.

Do you send an engineer for installation and operator training?

Yes. On-site installation, commissioning and operator training are available. Travel and accommodation are charged at cost and there is no separate service fee. Tell us the site location and we will estimate the number of days.
